A.O. Smith 146032 Century®II AC Motor, 10HP Frame 215T

​The A.O. Smith 146032 Century® II AC Motor is a robust 10-horsepower (HP) electric motor designed for industrial applications. It features a 215T frame size, operates at 460 volts (V), and draws 13 amperes (A) under full load conditions. The motor's nominal speed is 1760 revolutions per minute (RPM). ​ Key Specifications: Horsepower (HP): 10​ Voltage (V): 460​ Full Load Amperage (A): 13​ Speed (RPM): 1760​ Frame Size: 215T​ Shaft Diameter: 1-3/8 inches (1.375") Shaft Length (U Dimension): 3-3/8 inches (3.375") Base Mounting Hole Spacing (Bolt Centers): Front to Back: 5 inches Side to Side: 7-1/2 inches Overall Height (From Base to Shaft Centerline): 5-1/4 inches Bolt Hole Diameter: 5/8 inch (0.625") Keyway Size: 3/8 inch (0.375") Enclosure: Open Drip Proof (ODP)​ Phase: Three-phase​ This motor is designed for continuous duty in industrial settings, providing reliable performance for applications such as pumps, compressors, and conveyors. The Open Drip Proof (ODP) enclosure allows for effective cooling in environments free from excessive moisture and contaminants.​ Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   180.00

Depth:   20.00

Length:   20.00

Width:   20.00

SKU:   100836 4.R5.7.1
