Red Lion Controls 150FX-SC Industrial 4-Port Ethernet Switch

Red Lion Controls 150FX-SC is an industrial-grade unmanaged Ethernet switch designed for reliable networking in harsh environments. It provides fiber and copper connectivity for Ethernet-enabled industrial devices. Specifications: Manufacturer: Red Lion Controls Model Number: 150FX-SC Switch Type: Unmanaged Industrial Ethernet Switch Number of Ports: 4 total Port Configuration: 3 × 10/100Base-TX (RJ45), 1 × 100Base-FX (SC fiber port) Fiber Port Type: SC connector, multimode Fiber Range: Up to 2 km (multimode, 62.5/125 µm) Wavelength: 1310 nm Power Input: 10–30 V DC Power Consumption: < 3 W Operating Temperature: –40°C to +85°C Enclosure: IP30-rated metal housing Mounting: DIN rail or panel mount Certifications: UL, cUL, CE, Class I Div 2 (HazLoc), RoHS Dimensions: Approx. 4.3" H × 1.0" W × 3.6" D Applications: Industrial automation, SCADA, remote I/O, process control networks 4 RJ45 Ports, 1SC Fiber Ports, 100 Mbps, Unmanaged

Condition: New – Open box

Weight:   3.00

Depth:   12.00

Length:   12.00

Width:   12.00

SKU:   101318 4.S6.9.2
