Kollmorgen ME2-405-B-A2 Goldline Servomotor-Encoder Commutated

High-performance, brushless servomotor from the Kollmorgen Goldline series, designed for precise motion control applications requiring encoder-based commutation and high dynamic response. Model: ME2-405-B-A2 Series: Goldline Manufacturer: Kollmorgen Motor Type: Brushless AC servomotor Commutation: Encoder commutated Continuous Stall Torque: 13.4 Nm Peak Torque: 35 Nm Rated Speed: Up to 2500 RPM Voltage: 230V AC (nominal, depending on drive pairing) Full Cont. (Continuous Current): Line Amps (RMS): 10.0 Amps Full Peak (Peak Current): Line Amps (RMS): 27.4 Amps Feedback: High-resolution encoder (commutation and positioning) Frame Size: ME2 (NEMA 42 equivalent) Mounting: Flange mount Enclosure: TENV or TEFC (varies by configuration) Insulation Class: Class F Certifications: UL, CE compliant Applications: Robotics, packaging machinery, semiconductor equipment, CNC systems, and precision automation Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   34.60

Depth:   10.00

Length:   10.00

Width:   12.00

SKU:   1014 4.S7.1.1
