Festo MS6-SV-1/2-E-10V24-SO-MP1 Quick Exhaust Valve PNs: 548713/552252

This Festo safety quick exhaust valve, part of the MS6 series, is designed to safely and rapidly exhaust compressed air in pneumatic systems during emergency stop or controlled depressurization conditions. It combines safety venting and soft-start functionality, helping meet ISO 13849-1 performance requirements for machine safety. Technical Specifications Manufacturer: Festo Model: MS6-SV-1/2-E-10V24-SO-MP1 Part Numbers: 548713 (base unit), 552252 (modular variant/assembly) Valve Type: Safety quick exhaust valve with soft-start Port Size: 1/2" (G 1/2) Female thread 2-Channel Open silencer Operating Voltage: 24 VDC Operating Pressure: 4–10 bar Flow Rate: Up to 4000 l/min from right to left Function: Controlled pressure build-up and fast exhaust for safe depressurization Safety Function: Complies with ISO 13849-1, up to Performance Level e (PL e) Mounting: Modular installation within MS6 air preparation units or standalone Electrical Connection: M12 (5-pin or 4-pin depending on config) Actuation: Electrically actuated, monitored switching Soft-Start Feature: Gradual pressurization during startup to protect downstream components Protection Rating: IP65 Temperature Range: -10 °C to +60 °C Body Material: Polymer and aluminum alloy housing Diagnostics: Integrated sensor for feedback/status signal to controller Applications: Pneumatic safety circuits, emergency stop functions, machine tools, packaging lines

Condition: New

Weight:   10.00

Depth:   12.00

Length:   14.00

Width:   20.00

SKU:   101462 4.S2.6.4
