Danfoss PT5B20STR3DLF30A00C0 VLT 5005 Variable Speed Drive 380-500V 7.0A 4.0HP

Variable Frequency Drives

$1,450
$224.00
Save 85%

In stock 1 available

Quantity
Total Price: $224.00

Share this item:

Questions?

Danfoss PT5B20STR3DLF30A00C0 is a model from the VLT 5005 series of variable speed drives, designed for controlling 3-phase AC motors in industrial and commercial applications. This model supports 4.0 HP, operates on 380–500V AC, and delivers up to 7.0 A output current. Specifications: Manufacturer: Danfoss Series: VLT 5005 (Part of the VLT 5000 family) Model Number: PT5B20STR3DLF30A00C0 Motor Power: 4.0 HP (3.0 kW) Input Voltage: 380–500V AC, 3-phase Output Current: 6.3 A Output Frequency: 0–1000 Hz Control Method: V/Hz or Sensorless Vector Control Enclosure: IP20 (open chassis) Braking: Integrated brake chopper (external resistor required for braking) Cooling: Forced air (fan-cooled) Mounting: Wall or panel mount Ambient Temp Range: 0°C to +45°C (no derating), up to +55°C with derating Interface: Built-in keypad with LED or optional alphanumeric display Communication Options: RS-485, Modbus, Profibus (via optional modules) Application: Pumps, fans, conveyors, machine tools, HVAC, mixers, and process control systems

Brand:
DanfossNumber Of Phases

Condition: Used

Weight:   16.04

Depth:   16.00

Length:   26.00

Width:   18.00

SKU:   1166 4.S8.12.2
