ACT Electric SP-R Multi Purpose Pressure Switch

The ACT Electric SP-R is a rugged industrial pressure switch designed for use in air, oil, and water applications. It provides reliable monitoring and control with adjustable set points and a robust enclosure suitable for harsh environments. Model: SP-R Type: Pressure Switch Media Compatibility: Air, oil, water Adjustable Set Pressure Range: 0.5 to 5 MPa Maximum Pressure: 7 MPa Contact Rating (AC): 250V AC, 5A Contact Rating (DC): 30V DC, 2A Switch Type: SPDT mechanical contact Thread Connection: PT 1/4" Housing: Die-cast metal enclosure Enclosure Rating: Weather-resistant, sealed for industrial environments Set Point Adjustment: External dial with indicator window Mounting: Direct pipe or panel mount Temperature Range: -10°C to 60°C Manufacturer: ACT Electric (Korea) Application: Hydraulic and pneumatic systems, pressure regulation, process control Compliance: Industrial standard grade, CE marking depending on model Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   2.10

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   1250 4.S6.2.2
