Endress+Hauser FTL50H-ATC2AD4E6C Liquiphant M Vibrating Level Switch

The Endress+Hauser FTL50H-ATC2AD4E6C Liquiphant M is a hygienic vibrating level switch used for reliable point level detection of liquids in food, beverage, and pharmaceutical applications. It features stainless steel housing, high ingress protection, and is suitable for CIP/SIP processes. Model: FTL50H-ATC2AD4E6C Series: Liquiphant M Type: Vibrating Fork Level Switch Application: Point level detection of liquids Housing: Stainless steel (hygienic design) Process Connection: Typically Tri-Clamp, hygienic thread, or similar (E6C variant suggests hygienic fitting) Power Supply (U): 19…253 V AC, 50/60 Hz or 19…55 V DC Power Consumption: Pmax = 1.3 W Switching Capacity: 253 V AC, 6 A; 30 V DC, 6 A; 125 V DC, 0.2 A Switching Power: 1500 VA (cos φ = 1), 750 VA (cos φ = 0.7) Ambient Temperature Range: -50°C to +70°C Enclosure Rating: IP66/IP67 / NEMA 4X Features: Maintenance-free, immune to foam/bubbles/vibration, SIL2/3 capable Certifications: ATEX, EHEDG, 3-A (model-dependent) Typical Use: Food & beverage, biotech, pharmaceutical, hygienic tanks and pipelines Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   1.10

Depth:   6.00

Length:   12.00

Width:   9.00

SKU:   1630 4.S6.2.2
