Omron MY4N Relay 5Amp 24VDC Coil W/0240YT Socket Base Lot of 9

Omron MY4N Relay is a general-purpose, miniature 4-pole relay suitable for automation and control applications. It features a 24VDC coil and is supplied with a compatible PYF-series 0240YT socket base for DIN rail or panel mounting. Technical Specifications Relay Model: MY4N Socket Base: W/0240YT (PYF14A-E type) Contact Configuration: 4PDT (4 Form C) Contact Rating: 5A at 250VAC / 30VDC (resistive load) Coil Voltage: 24VDC Coil Power Consumption: Approx. 0.9W Operate Time: Max. 20 ms Release Time: Max. 20 ms Insulation Resistance: 100 MΩ min. (at 500 VDC) Dielectric Strength (Coil to Contacts): 2000 VAC, 50/60 Hz for 1 min Dielectric Strength (Between Contacts): 1000 VAC, 50/60 Hz for 1 min Mechanical Life: 10,000,000 operations min. Electrical Life: 500,000 operations min. (at rated load) Ambient Operating Temperature: -55°C to +70°C (no icing) Mounting Type: Plug-in with socket base Socket Type: 14-pin DIN rail or panel mount Indicator: LED indicator (optional on some versions) Weight: Approx. 35g (relay only), ~65g with socket Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.50

Depth:   4.00

Length:   6.00

Width:   4.00

SKU:   1631 4.S6.2.3
