Omron GT1-ID16DS Digital Input Unit

Omron GT1-ID16DS is a digital input unit designed for distributed I/O systems using the DeviceNet network. It offers 16 NPN input points and a 25-pin D-sub connector, making it ideal for compact, modular machine control applications. Technical Specifications Model: GT1-ID16DS Manufacturer: Omron Corporation Unit Type: Digital Input Module Input Points: 16 points Input Type: NPN (sinking) Rated Input Voltage: 24VDC Input Voltage Range: 15–30VDC Input Current: Approx. 4 mA per point Response Time: OFF→ON: 1.0 ms / ON→OFF: 1.0 ms (typical) Connector Type: 25-pin D-sub (female) Internal Current Consumption: Approx. 60 mA max I/O Power Supply Voltage: 20.4–26.4VDC Status Indicators: LED for each input channel Mounting: DIN rail mount Protection: Short-circuit and overvoltage protection on inputs Network: DeviceNet slave (via GT1 bus connector) Operating Temperature: 0°C to +55°C Dimensions: 30mm (W) × 90mm (H) × 70mm (D) Weight: Approx. 150g Application: Distributed I/O in Omron PLC systems (NSJ, CJ1, etc.) Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.20

Depth:   4.00

Length:   7.00

Width:   7.00

SKU:   1669 4.S7.16.3
