Potter&Brumfield SSRT-240D10 Solid State Relay, In 120/240VAC Out 3-32VDC

Solid state relay designed for reliable switching of DC loads using voltage AC control. Offers optically isolated input and zero-cross switching for noise reduction and enhanced durability in industrial automation and control systems. Input Voltage: 24–280 VAC Output Voltage: 3–32 VDC Maximum Load Current: 10 A Control Current: 3.0–25 mA Turn-On Time: ≤1 cycle (8.3 ms max) Turn-Off Time: ≤1/2 cycle (8.3 ms max) Input-Output Isolation Voltage: 4000 VRMS Output Type: Zero-crossing Mounting Style: Panel mount Operating Temperature Range: -30°C to +80°C Housing Material: Epoxy encapsulated Weight: Approximately 3 oz (85 g) Terminals: Screw-type for input and output connections LED Indicator: Yes (input status) Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.10

Depth:   4.00

Length:   7.00

Width:   7.00

SKU:   1705 4.S9.13.5
