AutomationDirect ZL-RFU40 ZipLink Fuse Block 40-pin 30VDC

Compact 40-pin ZipLink fuse block designed for rapid wiring of I/O modules with built-in fuse protection. Ideal for 30VDC control applications in industrial panels. Model: ZL-RFU40 Number of Pins: 40 Rated Voltage: 30 VDC Rated Current per Channel: 30mA max Fuse Type: 5 x 20 mm, field replaceable Fuse Protection: Individual fuse per channel LED Indication: Yes (per blown fuse) Connection Type: Ribbon cable connector (for ZipLink-compatible I/O modules) Mounting Style: DIN rail Terminal Type: Removable screw terminal blocks Operating Temperature Range: 0°C to +60°C Housing Material: Polycarbonate Dimensions (W x H x D): Approx. 168 x 90 x 60 mm Approvals: UL Recognized, CE Marked Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   1.00

Depth:   16.00

Length:   12.00

Width:   10.00

SKU:   1713 4.S8.10.3
