Analog Devices 3B02 8-Channel Backplane

Analog Devices 3B02 is an 8-channel backplane used to mount and interconnect 3B Series signal conditioning modules. It provides power and signal routing for up to eight individual plug-in modules used in industrial and instrumentation applications. Model: 3B02 Type: Backplane for 3B Series Modules Channels: 8 independent module slots Module Compatibility: Analog Devices 3B Series (e.g., 3B30, 3B31, 3B40, etc.) Power Supply Input: ±15 VDC (typical) Signal Output: Unipolar or bipolar analog signal (typically ±5 V or 0–5 V) Connection Interface: – Screw terminals for field wiring – 26-pin ribbon connector for system I/O – Terminals for ±15V DC power input Isolation: Maintains full isolation per module specifications Mounting: DIN rail or panel mount Dimensions: Approx. 7.2" L x 5.1" W x 1.2" H Application: Signal conditioning, industrial data acquisition, process control Manufacturer: Analog Devices Made In: USA This backplane is ideal for applications requiring centralized signal conditioning and easy interface between field sensors and data acquisition systems. Please review pictures carefully and let us know if you have any questions!

Condition: Used
