Bimba M-173.5-DPY Pneumatic Air Cylinder 1-1/2" Bore 3-1/2" Stroke

Hydraulic & Pneumatic Cylinders

$156
$32.60
Save 79%

In stock 2 available

Quantity
Total Price: $32.60

Share this item:

Questions?

Bimba M-173.5-DPY is a round-body, double-acting pneumatic air cylinder designed for versatile linear motion applications. This model includes a magnetic piston and rear pivot mounting, making it suitable for use with position sensors and swing-arm linkages. Model: M-173.5-DPY Series: Original Line® Type: Double-Acting Pneumatic Cylinder Bore Size: 1-1/2 inch Stroke Length: 3-1/2 inch Mounting Style: Rear Pivot (Y-type clevis) Piston Type: Magnetic piston for position sensing (DP = Double-acting with magnet) Operating Pressure: Up to 250 PSI (air only) Rod Type: Single-end rod, stainless steel Rod Thread: Male (standard) Body Material: Clear anodized aluminum End Caps: Aluminum with tie-rod construction Temperature Range: –20°F to +160°F (standard Buna-N seals) Port Type: NPT female ports Application: Suitable for automation, clamping, lifting, part ejection, and positioning tasks Manufacturer: Bimba Manufacturing Company Made In: USA Please review pictures carefully and let us know if you have any questions!

Brand:
BimbaMPN

Condition: Used

Weight:   1.00

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   1952 4.S9.8.2
