Analog Devices DB-24 Manifold Card Input-Output 24-Channel

Analog Devices DB24 is a 24-channel I/O manifold (termination) board used to interface field wiring with Analog Devices data acquisition systems or signal conditioning modules. It provides a clean, organized means of connecting discrete I/O signals. Model: DB24 Type: Digital/Analog I/O Terminal Board Channels: 24 (grouped in sets of 4: 0–3, 4–7, ..., 20–23) Function: Breakout board for connecting sensors, switches, or other field devices Input/Output Support: Compatible with both digital and analog signals (system-dependent) Connector Type: – Screw terminals for field wiring – Gold-plated edge connector (J1) for system interface Power Terminals: + and – terminal for external power or grounding PCB Labeling: Clearly marked terminal groupings and channel numbers Mounting: Panel or enclosure mountable via corner holes Compatibility: Works with Analog Devices DAQ systems and possibly with 3B/5B signal conditioning modules via backplanes Manufacturer: Analog Devices Made In: USA Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.20

Depth:   6.00

Length:   12.00

Width:   9.00

SKU:   1962 4.S8.8.3A
