Keyence AP-15SK Digital Pressure Sensor 20MPa with AP-V80W Switch

High-precision digital pressure sensor paired with an auto-switch, designed for accurate monitoring and switching in high-pressure hydraulic or pneumatic systems. Model: AP‑15SK sensor, AP‑V80W switch Pressure Range: 0 to 20 MPa (0–2900 psi) Accuracy (Sensor): ±0.5 % F.S. (standard); ±0.2 % F.S. (high-accuracy type) Repeatability: ±0.2 % F.S. Resolution: 4 digits (±9999 counts) Output (Sensor): Voltage (1–5 V), current (4–20 mA), digital communication option (RS‑485) Switch Types (AP‑V80W): 1–4 settable NPN/PNP open collector outputs Response Time: 1 ms (sensor), 0.5 ms (switch) Supply Voltage: 12–24 V DC ±10 % Operating Temperature: -10 °C to 60 °C (22 °F to 140 °F) Pressure Port: M10 × 1 male Fluid Media: Air, hydraulic oil (ISO VG32, VG46, VG68) Electrical Connector: M12 × 1 4-pin quick disconnect Display: 4-digit LED indicator (switch status, pressure reading) Setting Method: Front-key operation or remote setting via digital input Output Characteristics: Switch hysteresis 0.2 % F.S. (switch point ± dead band) Protection Rating: IP67 (sensor head), IP40 (switch unit) Mounting: Panel or DIN rail (switch); direct inline for sensor Construction Materials: Stainless steel sensing element, aluminum housing Approvals: CE, RoHS Storage Temperature: -20 °C to 70 °C (-4 °F to 158 °F) Weight: Sensor ~120 g; Switch ~75 g Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   1.20

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   1986 4.S8.11.4
