Keyence SL-C32H-R Safety Light Curtain Transmitter

The SL-C32H-R is a high-performance transmitter unit of a Type 4 safety light curtain system from Keyence, engineered to ensure machine safety by detecting personnel or objects entering hazardous zones. It offers reliable operation in harsh industrial environments with advanced optical performance. Model: SL-C32H-R System Type: Safety Light Curtain (Transmitter only) Series: SL-C Number of Beam Channels: 32 Protective Height: 319 mm (12.56 in) Light Source: Infrared LED (emitted from transmitter) Response Time: 15 ms Operating Range: 620 mm Supply Voltage: 24 VDC ±10% Current Consumption: 81 mA (transmitter only) Interface: Uses proprietary synchronization and safety logic with paired SL-C receiver Protection Rating: IP65 Housing Material: Aluminum body with polycarbonate lens cover Mounting: M5 tapped holes; brackets optional Ambient Temperature: -10 °C to +55 °C (14 °F to 131 °F) Cable Connection: M12 connector or pigtail (model variant dependent) Standards: Complies with IEC61496-1/2 Type 4, ISO 13849-1 PLe, SIL 3 Applications: Presses, robotic cells, conveyors, pick-and-place machinery, and other hazardous zones requiring personnel protection Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.90

Depth:   16.00

Length:   26.00

Width:   18.00

SKU:   2003 4.S7.8.4
