Phoenix Contact FLK 10 CH-NR 91601 Interface Module

The FLK 10 CH-NR 91601 is a DIN-rail mountable interface module from Phoenix Contact. It simplifies wiring between PLC control systems and field devices by converting a 10-pin ribbon cable connection into discrete screw terminal outputs. Model: FLK 10 CH-NR 91601 Connector Type: 10-position IDC ribbon cable header (2.54 mm pitch) Terminal Points: 10 screw-type terminals for field wiring Mounting: DIN rail (NS 35 or NS 32) Conductor Size: 0.2 to 2.5 mm² (solid or stranded) Voltage Rating: Up to 60 VDC / 50 VAC Current Rating: Up to 1 A per contact Housing Material: Green thermoplastic (PA6) Protection: IP00 (open terminal); higher when installed in enclosure Operating Temperature: -20°C to +50°C Installation: Passive interface module for signal distribution Application: PLC and I/O module termination, signal marshalling, sensor/actuator wiring Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.30

Depth:   4.00

Length:   7.00

Width:   7.00

SKU:   2097 4.S10.1.3I
