Bussmann OPM-1038R Overcurrent Protection Module 600V 30Amp Class CC Fuses

Bussmann OPM‑1038R is a 3‑pole indicating overcurrent protection fuse holder module designed for Class CC fuses in industrial control systems, offering safe and easy fuse installation and status indication. Voltage Rating: 600 VAC/VDC Amperage Rating: 30 A Fuse Type: Class CC (13/32″ × 1½″) Poles: 3 Interrupt Rating (AC/DC): 200 kA ICR Wire Size (Stranded): #8–18 AWG Wire Size (Solid): #10–18 AWG Mounting: 35 mm DIN‑rail or #8 screw panel mount Fuse Diameter: 13/32 in (10 mm) Fuse Length: 1½ in (38 mm) Dimensions (H×W×D): 3.6″ × 1.76″ × 3.74″ Housing Material: Gray thermoplastic (UL94 V‑0) Features: dead‑front, finger‑safe terminals, cam‑action handle, removable module, padlockable, fuse‑blown indicator lights, remote status output option Status Output Voltage: 5–35 V DC (or up to 300 V AC) Status Output Current: max 40 mA Status Output Resistance: on < 35 Ω; off > 10 MΩ Mounting Clips: Class CC rejection or European 10×38 mm clips Certifications: UL 512, CSA C22.2 No. 39, CE, RoHS compliant Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.10

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   2104 4.S8.10.3
