HPtec UXS030DC-5 DC Servo Driver 8-30VDC

HPtec UXS030DC-5 is a compact full-digital DC servo driver designed for high-precision control of DC and brushless motors in position, speed, or torque modes. It supports a wide input voltage range and multiple feedback options, suitable for automation and motion control applications. Voltage Input: 8–30 VDC Control Modes: Position, speed, torque Current Loop Sampling Rate: 15 kHz Speed/Position Loop Sampling Rate: 3 kHz Pulse Input: Differential up to 2 Mpps; open-collector up to 500 Kpps PWM Input: 1 kHz–100 kHz; ±10 V analog Digital Inputs: 10 (IN6–IN10 high-speed; IN5 supports thermistor) Digital Outputs: 3 (NPN low-active, 30 VDC, 300 mA max) Encoder Feedback: Incremental, sine/cosine, resolver, Hall sensor Communication Ports: RS-232 (9600–115200 bps), CANopen DS-402 (20 kbps–1 Mbps) Protection Functions: Overcurrent, over/undervoltage, I²t, short circuit, overload, overheating, encoder error, position error Operating Temperature: 0–40 °C Humidity Range: ≤ 80 % RH (non-condensing) Altitude Limit: < 1000 m Vibration Resistance: < 4.9 m/s² Shock Resistance: < 19.6 m/s² Mounting: Panel or chassis mount Compatible Motors: Brushed DC, brushless DC, linear, stepper, voice-coil Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.20

Depth:   4.00

Length:   7.00

Width:   7.00

SKU:   2118 4.S8.8.4A
