GE Fanuc IC200MDL740E Output Module 12-24VDC

PLC Input & Output Modules

$267
$65.40
Save 76%

In stock 1 available

Quantity
Total Price: $65.40

Share this item:

Questions?

This is a VersaMax discrete output module designed for industrial control applications. It provides 16 positive logic outputs capable of switching DC loads with flexible voltage and current ratings suitable for various automation tasks. Module Type: Discrete Output Module Model Number: IC200MDL740E Output Type: Positive logic (sourcing) Number of Outputs: 16 points Output Voltage Range: 12–24 VDC Output Current: 0.5 A per point Output Grouping: Single group of 16 outputs Maximum Inrush Current: 1 A for 10 ms Switching Frequency: 100 Hz typical resistive load Status Indicators: Individual LED for each output Isolation: 250 VAC continuous between field side and logic side Environmental Ratings: Operating Temperature: 0°C to 60°C Storage Temperature: -40°C to 85°C Hazardous Location Certification: Class I Div. 2 Groups A, B, C, D ATEX Zone 2 (II 3G Ex nA IIC T4X Gc) Agency Approvals: UL, CE, CSA Pilot Duty Rating: 0.5 A at 24 VDC Manufacturer: GE Fanuc Country of Origin: USA Please review pictures carefully and let us know if you have any questions!

Brand:
GE FanucMPN

Condition: Used

Weight:   0.10

Depth:   6.00

Length:   12.00

Width:   9.00

SKU:   2250 4.S7.9.4
