In stock 1 available
The DB-24 is a 24-channel digital I/O interface board developed by Analog Devices for industrial automation and data acquisition systems. It provides optically isolated input and relay output channels to ensure safe and reliable operation in electrically noisy environments. Model: DB-24 Type: Digital I/O Interface Board Total Channels: 24 (configurable as input/output, depending on variant) Channel Configuration: DB-24PR: 24 relay output channels DB-24P: 24 opto-isolated input channels DB-24PD: Mixed configuration (12 in / 12 out or other variants) Isolation Voltage: 2500 Vrms (input/output isolation) Relay Type (DB-24PR): SPST, electromechanical Relay Voltage Rating: Up to 250 VAC / 30 VDC Relay Current Rating: 2 A per channel (resistive load) Input Voltage Range: 5–24 VDC (logic level detection) Indicators: LED status indicators for each channel Power Supply: Typically 5 VDC or 12–24 VDC (model-dependent) Connector: 50-pin flat cable header (compatible with DAQ and control cards) Mounting: Screw holes for panel mounting or DIN rail bracket (optional) Application: Data acquisition systems, industrial control, PLC expansion, signal monitoring Manufacturer: Analog Devices / Automation Interface Division (legacy) Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 0.40
Depth: 4.00
Length: 10.00
Width: 8.00
SKU: 2281 4.S8.8.5A
