Siemens 3VU1300-1MJ00 Motor Starter-Protector, 600 VAC 25A Range 2.4-4.0Amp

Compact motor protection circuit breaker designed to protect motors from overload, short-circuit, and phase failure. Suitable for use in manual motor control applications up to 690V AC. Model: 3VU1300-1MJ00 Rated Operational Voltage (Ue): 690V AC Rated Insulation Voltage (Ui): 690V Rated Current Range (Adjustable): 2.4 – 4.0 Amps Rated Interrupting Capacity at 415V: 100 kA Rated Interrupting Capacity at 690V: 2 kA Utilization Category: AC-3 Frequency: 50/60 Hz Control Voltage: Manual Trip Class: Class 10 Short Circuit Release: Fixed at 50A Mounting: DIN rail or screw mounting Integrated Auxiliary Contacts: 1 NO + 1 NC Temperature Range: -25°C to +60°C Standards: IEC 60947-4-1, IEC 60947-2, VDE 0660 Motor Rating: Up to 5.5 kW @ 400V (approx. 7.5 HP) Frame Size: S00 Please review pictures carefully and let us know if you have any questions!
