Moeller PKZM1-1 Manual Motor Starter-Protector 600V 5Amp Range 0.6-1.0Amp

Compact motor protection device for manual control and reliable protection of motors against overload and short circuit, typically used in industrial control panels. Model: PKZM1-1 Manufacturer: Moeller (now Eaton) Rated Operating Voltage (Ue): 690V AC Rated Current: 0.6-1 Amp (adjustable) Adjustment Range: Fixed at 1A for this variant Short Circuit Breaking Capacity: 150 kA (with appropriate backup fuse) Tripping Characteristics: – Thermal overload trip (long-time delay) – Magnetic short-circuit trip (instantaneous) Trip Class: Class 10 Rated Frequency: 50/60 Hz Mounting: DIN rail Control Type: Manual switch (ON/OFF/Tripped) Integrated Auxiliary Contact: 1 NO + 1 NC Standards: IEC/EN 60947-2, IEC 60947-4-1, UL 508, CSA Application: Motor protection, machine control panels, switchgear assemblies, HVAC and pump systems Environmental Protection: IP20 (front), higher with enclosure or accessory covers Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.40

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   2413 4.S7.12.3
