Siemens 3VE1010-2E Motor Starter-Protector 600 VAC 7.5Amp Range 0.4-0.63Amp

Thermal-magnetic motor starter designed to protect motors from overload, short circuit, and phase loss, with an adjustable current range and a high interrupting capacity for safe operation in industrial systems. Model: 3VE1010-2E Rated Operating Voltage (Ue): 600V AC Current Adjustment Range: 0.4 – 0.63 Amps Maximum Motor Current (AC-3): 7.5 Amps Interrupting Capacity: – 100 kA at 415V – 50 kA at 690V Rated Frequency: 50/60 Hz Trip Class: Class 10 Control Type: Manual ON/OFF switch Standards: IEC 947-2, IEC 947-4-1, VDE 0660, UL, CSA Mounting: DIN rail or panel mount Auxiliary Contact Options: Available separately Protection Functions: – Overload protection via thermal element – Short-circuit protection via magnetic trip – Phase loss sensitivity Application: Motor protection in HVAC systems, pumps, fans, conveyors, and automation panels Made in Germany Please review pictures carefully and let us know if you have any questions!
