In stock 1 available
The Rittal 9951146 is a TS 8 Compact Disconnect Enclosure designed for industrial applications requiring secure and organized housing of electrical components. With its robust construction and modular design, it offers flexibility and durability for various installations. Model: TS 9951.146 Type: Compact Disconnect Enclosure Series: TS 8 Material: Carbon Steel Finish: Dipcoat-primed, powder-coated on the outside with textured paint Color: Light Gray (RAL 7035) Dimensions (W × H × D): 39.4 in × 78.7 in × 23.6 in (1000 mm × 2000 mm × 600 mm) NEMA Rating: NEMA 12 / IP55 Mounting Type: Floor-standing Door Configuration: Single Door with Hinged Trim Panel Enclosure Frame Thickness: 1.5 mm Door Thickness: 2.0 mm Mounting Plate Thickness: 3.0 mm Included Components: Enclosure frame with doors and roof plate Rear panel Gland plate Mounting plate 4 eyebolts Padlock Comfort handle Flange door with low amperage adapter plate (pre-installed) Ride-Up Roller (pre-installed) Features: Mechanical interlock prevents doors from being opened while the system is energized; all doors must be closed to power the system ON. Simplified installation with a slimmer flange door providing access behind the operator handle. Adapter plates available for high and low amperage handles. Compatible with most commercially available operator handles. Expandable and modular design compatible with all standard TS 8 accessories.
Condition: New
Weight: 151.00
Depth: 60.00
Length: 48.00
Width: 48.00
SKU: 254860 4.R10.6.4
