In stock 1 available
The Moritex ML-M0822UR is a high-resolution macro/CCTV lens designed for machine vision applications. It features a compact design with vibration-resistant construction, making it suitable for industrial environments. The lens supports a resolving power of 200 line pairs per millimeter at the center, accommodating pixel sizes as small as 2.2 µm. It is compatible with 2/3" sensors and has a focal length of 8 mm. Technical Specifications: Focal Length: 8 mm Aperture (F-number): Adjustable from f/2.2 to f/16 Image Format: Supports up to 2/3" sensors (11 mm diagonal) Resolving Power: 200 lp/mm at the center, 100 lp/mm at the margins Minimum Working Distance: 100 mm Filter Thread: M25.5 x 0.5 Dimensions: Diameter 29.5 mm x Length 37.8 mm Weight: Approximately 60 g The lens is equipped with a VIS/NIR anti-reflective coating, enhancing performance across visible to near-infrared wavelengths. It also includes locking set screws for both focus and iris adjustments, ensuring stability in settings where vibration may be a concern.
Condition: New
Weight: 3.00
Depth: 6.00
Length: 6.00
Width: 6.00
SKU: 258850 4.S1.18.11
