Allen-Bradley MPAS-B80242-V20S2A SER.B Linear Stage Actuator, 240mm Stroke

The Allen-Bradley MPAS-B80242-V20S2A is a precision MP-Series™ Integrated Linear Stage Actuator, designed for high-performance positioning in industrial automation applications such as material handling, electronics assembly, and precision packaging. Model: MPAS-B80242-V20S2A Series: MP-Series™ Integrated Stage – SER. B Type: Linear Stage Actuator (ballscrew-driven) Mechanical Specifications Frame Size: 8 (200 mm / 7.9 in base width) Stroke Length: 240 mm Ballscrew Lead: 20.0 mm/rev (0.79 in/rev) Ballscrew Type: Rotary motor-driven ballscrew Feedback Device: Multi-turn high-resolution absolute encoder Encoder Resolution: 128 cycles/rev (rotary encoder) Linear Resolution: Determined by ballscrew lead × encoder resolution Mounting Orientation: Horizontal or vertical Linear Bearing: Integrated for precise guidance and load support Repeatability: ± typically within microns (based on drive/controller settings) Electrical Specifications Input Voltage: 460V AC (3-phase) Motor Type: Integrated servo motor (rotary) Motor Feedback: Integrated with encoder (absolute feedback) Power/Signal Connection: Circular industrial connectors (user-cabled) Brake: Optional (not specified in this model code)

Condition: New

Weight:   75.00

Depth:   14.00

Length:   24.00

Width:   42.00

SKU:   258885 4.R3.2.4
