Kollmorgen 00D12A02100-1 Platinum™ DC Servo Motor

The Kollmorgen 00D12A02100-1 is a DC servo motor from their Platinum Series, engineered for high-performance applications requiring precision and reliability. This motor features an ironless disc armature design, which contributes to zero cogging and ensures smooth operation, particularly at low speeds. ​ Key Specifications: Rated Torque: 91.8 N-cm at 25°C ambient temperature; 81.7 N-cm at 40°C.​ Rated Speed: 3,000 RPM.​ Maximum Speed: 6,000 RPM.​ Rated Continuous Current: 8.65 Amps.​ Peak Current: 84 Amps.​ Rated Terminal Voltage: 43.3 Volts.​ Armature Resistance: 0.61 Ohms.​ Terminal Resistance: 0.75 Ohms.​ Power Output: 275 Watts. ​

Condition: Used

Weight:   10.00

Depth:   12.00

Length:   12.00

Width:   12.00

SKU:   259529 4.S3.8.2
