KEL J1 20 VMEbus Backpanel Board

The KEL J1 20 is a VMEbus (Versa Module Europa bus) backplane board used to interconnect VMEbus modules within a chassis. It provides 21 slots (1 system slot + 20 user slots) for J1 connectors, which support the A24/A32 address and D16/D32 data transfers of the VMEbus standard. Technical Data: Type: VMEbus J1 backplane Number of Slots: 21 (1 system slot, 20 user slots) Bus Support: VMEbus A16/A24/A32, D08/D16/D32 (J1 signal lines only) Connectors: DIN 41612, 96-pin (Row A, B, C) Backplane Type: Passive Signal Distribution: Differential and single-ended lines per VMEbus standard Board Type: Multilayer PCB with controlled impedance Terminations: On-board termination resistors for signal lines Cooling Considerations: Requires chassis with forced air cooling Dimensions: Standard 6U Eurocard height, full-width backplane Mounting: Rack/chassis mountable with screw holes and card guides Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   5.00

Depth:   12.00

Length:   14.00

Width:   20.00

SKU:   259612 4.S8.9.4B
