1734MB Mounting Base & 1734RTB3S Terminal Block Specification
1734MB Mounting Base
Model: 1734MB
Type: Mounting Base for POINT I/O
Mounting: DIN Rail Mount
Function: Provides interconnection between the POINT Bus Backplane and the Field Power-Bus
Additional Features: Inbuilt removable terminal block for easy wiring and replacement
1734RTB3S Terminal Block
Model: 1734RTB3S
Type: Terminal Block for POINT I/O System
Position: 12 Position
Connection Type: Spring Type
Current Rating: 2 Amp
Voltage Rating: 30 V
Protection Rating: IP20 (Protection against solid objects larger than 12mm in diameter)
Replacement: Compatible replacement for 1734 terminal blocks
Key Features
- 1734MB Mounting Base: Provides a reliable connection between the backplane and field power bus in the POINT I/O system.
- DIN Rail Mount: Ensures easy installation and secure mounting in control cabinets.
- 1734RTB3S Terminal Block: Features a 12-position spring-type connection for secure and simple wiring.
- Current and Voltage Ratings: Rated for 2 Amps and 30 V for safe and efficient operation.
- Protection Rating: IP20 ensures protection from dust and small objects, ideal for control environments.
The 1734MB Mounting Base and 1734RTB3S Terminal Block are designed for seamless integration within the POINT I/O system, providing efficient and reliable interconnection between field power and the backplane.
</body>
</html>
Please review pictures carefully and let us know if you have any questions!
