Eaton DIL M7-01 Contactor, 600VAC/250VDC 20A
Key Features
- Model: Eaton DIL M7-01 Contactor (Replaced by XTCE007B01TD)
- Voltage Rating: Suitable for 600VAC and 250VDC applications.
- Current Rating: 20A, designed for both high voltage AC and DC circuits.
- Contact Configuration: 3-pole contactor with 1 normally closed contact.
- Power Rating: 3 kW for reliable performance in various industrial applications.
- Coil Voltage: 24V DC for energizing the contactor.
- Compact Design: Small-sized contactor suitable for space-constrained applications.
- Replacement: The DIL M7-01 is replaced by the XTCE007B01TD, offering enhanced features.
Specifications
- Model Number: DIL M7-01 (Replaced by XTCE007B01TD)
- Voltage Rating (AC): 600VAC, ideal for high-voltage AC applications.
- Voltage Rating (DC): 250VDC, providing versatility in DC circuits.
- Current Rating: 20A, capable of handling high current loads.
- Number of Poles: 3-pole contactor, suitable for controlling three-phase systems.
- Contact Configuration: Includes 1 normally closed contact for specific switching requirements.
- Power Rating: 3 kW, suitable for industrial machinery and electrical equipment.
- Coil Voltage: 24V DC for compatibility with low-voltage control systems.
- Mounting Type: Typically DIN rail or panel-mounted for convenient installation.
- Dimensions: Compact size, ensuring ease of integration into control panels or electrical systems.
Applications
The Eaton DIL M7-01 Contactor is suitable for various industrial applications:
- Industrial Control Systems: Ideal for controlling high-voltage AC and DC circuits in machinery and equipment.
- Motor Control: Used for controlling the start and stop of motors in industrial machinery and conveyors.
- Automation Systems: Employed in automation systems to control and switch electrical circuits.
- HVAC Systems: Controls circuits in heating, ventilation, and air conditioning systems.
- Power Distribution: Used in power distribution systems for switching operations and overload protection.
Additional Information
The Eaton DIL M7-01 Contactor offers reliable switching performance for industrial control systems. With its robust construction and versatile voltage ratings of 600VAC and 250VDC, this contactor can handle various load requirements in both AC and DC circuits. The compact design, high current rating of 20A, and 3-pole contact configuration make it ideal for use in industrial applications, automation, motor control, and power distribution. For applications requiring lower voltage control, the contactor operates with a 24V DC coil. The DIL M7-01 has been replaced by the XTCE007B01TD, offering improved features while maintaining compatibility with existing systems.
