Festo 8035533 Pressure Sensor

Festo 8035533 is a compact and versatile pressure sensor designed for precise monitoring of relative pressure in pneumatic systems. It supports multiple output formats and is suitable for a wide range of industrial automation applications. Specifications: Manufacturer: Festo Part Number: 8035533 Model: SPAN-P10R-G18M-PNLK-PNVBA-L1 Pressure Range: 0 to 10 bar (145 psi) Overload Pressure: Up to 15 bar Accuracy: ±1.5% of full scale Repeatability: ±0.3% of full scale Temperature Coefficient: ±0.05% FS/K Operating Medium: Compressed air (ISO 8573-1:2010 [7:4:4]) and inert gases Medium & Ambient Temperature: 0°C to +50°C Switching Outputs: 2 × PNP or 2 × NPN (selectable) Analog Outputs: 0–10 V, 1–5 V, or 4–20 mA Max Output Current: 100 mA Electrical Connection: 4-pin plug connector Pneumatic Connection: G1/8 male and M5 female threads Display: LCD with selectable units (bar, MPa, psi, etc.) Protection Class: IP40 Housing Material: Reinforced polyamide (PA) Media-contact Materials: Stainless steel and FPM seals Mounting Options: Panel mount, wall mount, or direct connection Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   2.00

Depth:   6.00

Length:   6.00

Width:   6.00

SKU:   260964 4.S6.5.4
