SMC CQ2B25-50-DUS01870 Pneumatic Compact Cylinder, Bore 25mm Stroke 50mm

Compact and lightweight pneumatic cylinder from SMC's CQ2 series, designed for space-constrained applications requiring efficient linear motion. Technical Specifications Model: CQ2B25-50-DUS01870 Series: CQ2 Type: Double-acting, single-rod pneumatic compact cylinder Bore Size: 25 mm Stroke Length: 50 mm Mounting Style: Through-hole or tapped (CQ2 series standard) Port Size: M5 or 1/8" (depends on sub-variant) Cushion: Rubber bumper Magnet: Built-in (for auto switch compatibility) Rod End Thread: Male Operating Pressure Range: 0.1 to 1.0 MPa Ambient and Fluid Temperature: -10°C to +70°C Body Material: Aluminum alloy Auto Switch Capability: Yes (DUS type indicates switch-ready version)

Condition: Used

Weight:   3.00

Depth:   6.00

Length:   6.00

Width:   6.00

SKU:   274009 4.S4.8.4
