Allen-Bradley T-CELL 02 Control Panel W/6176M-15PT Operator Display

Industrial operator interface panel integrating an Allen-Bradley 6176M-15PT touchscreen display. Built for factory floor control and monitoring, ideal for use in automation cells such as robotic workstations or CNC machine clusters. Technical Specifications (Display Unit – 6176M-15PT): Model: 6176M-15PT Type: Industrial flat panel monitor (touchscreen) Display Size: 15" TFT LCD Resolution: 1024 × 768 (XGA) Touch Interface: Resistive touchscreen Input Voltage: 100–240 VAC, 50/60 Hz (via panel power) Mounting: Panel mount with gasket seal Bezel Material: Aluminum with NEMA 4X/IP65 rating (front panel) Communication Ports: VGA/DVI, USB, Serial (varies by configuration) Operating Temperature: 0°C to 50°C Storage Temperature: -25°C to 60°C Control Panel Features: Emergency Stop: 1 × Mushroom-head emergency stop button (top-right corner) Control Buttons: – Green pushbutton: Likely for START – Black pushbutton: Function (custom programmable) – Blue illuminated pushbutton: Possibly RESET or auxiliary – Key switch: Mode selection or override access Panel Label: "T-CELL 02" (identifies its automation cell deployment) Enclosure Type: Likely stainless steel with integrated handle guards Side Handles: Blue anodized aluminum for handling or safety Ingress Protection: Likely IP65 or better (based on enclosure and HMI rating) Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   25.00

Depth:   12.00

Length:   18.00

Width:   24.00

SKU:   275531 N.A
