Allen-Bradley 1756-OB16IEFS ControlLogix 16-Point Digital Output

Allen-Bradley 1756-OB16IEFS is a high-performance 16-point digital output module for ControlLogix systems. It provides isolated, electronically fused DC outputs with fault status and Sequence of Events (SOE) capabilities, designed for safety and high-speed applications. Model: 1756-OB16IEFS Type: ControlLogix 16-Point Isolated DC Digital Output Module Output Type: Sourcing (10–30 VDC) Output Current Rating: – 1 A per channel @ 60°C – 2 A @ 45°C (max 4 channels simultaneously) Inrush Current: 4 A (pilot duty) Isolation: Channel-to-channel and channel-to-backplane Backplane Current Draw: – 320 mA @ 5.1 VDC – 3 mA @ 24 VDC Features: – Individual electronic fusing – Fault status and diagnostics – Sequence of Events (SOE) with timestamping Certifications: – UL, CE, CCC, EAC, ATEX, IECEx (Class I, Div 2, Groups A–D) – Temperature Code T4 Operating Temp: 0°C to 60°C Firmware Version: 1.011 Manufacturer: Rockwell Automation (Allen-Bradley) Made in: USA Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   3.00

Depth:   8.00

Length:   8.00

Width:   8.00

SKU:   275552 4.S2.12.3F
