Ewellix CASM-40-BS-0300AA-000 Electric Linear Actuator, Bore 40mm Stroke 300mm

The Ewellix CASM-40-BS-0300AA-000 is a high-performance electric linear actuator designed to replace pneumatic cylinders in industrial automation applications. It offers precise motion control, high force output, and modular compatibility with various motors. Model: CASM-40-BS-0300AA-000 Manufacturer: Ewellix Series: CASM-40 Actuator Type: Electric linear actuator Drive Mechanism: Ball screw Screw Size: 12 mm diameter x 5 mm lead Stroke Length: 300 mm Bore Size: 40 mm Maximum Dynamic Axial Force: 2,375 N Maximum Speed: 300 mm/s Duty Cycle: 100% Positioning Accuracy: ±0.01 mm (with appropriate motor feedback) Protection Rating: IP54S Operating Temperature Range: 0°C to +50°C Mounting Compatibility: ISO 15552 Motor Compatibility: Compatible with various brushless DC and servo motors Housing Material: Anodized aluminum profile Features: Modular design for easy motor integration Low backlash for high precision Lubricated for life Integrated anti-rotation device Applications: Industrial automation, packaging, robotics, and other applications requiring precise linear motion control Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   8.00

Depth:   8.00

Length:   8.00

Width:   16.00

SKU:   275767 4.S3.8.1
