Sick WL12-3P2431 Photoelectric Sensor

SICK WL12-3P2431 Photoelectric Sensor is a compact photoelectric reflex sensor with a polarized retroreflective detection principle. It is ideal for precise object detection in automation systems, using visible red light and offering simple installation and alignment with standard M12 connector. Sensing principle: Photoelectric sensor, retroreflective with polarization filter Sensing range: 0.07 m to 7.00 m (with PL80A reflector) Light source: LED, visible red light Wavelength: 640 nm Output type: PNP Output function: Light/dark switching Switching output: 1 x PNP Output current: Max. 100 mA Supply voltage: 10–30 V DC Connection type: M12, 4-pin connector Housing material: ABS plastic Lens cover: PMMA Enclosure rating: IP67 Ambient operating temperature: -25 °C to +60 °C Response time: ≤ 0.5 ms EMC: According to EN 60947-5-2 Installation: Any position Cable orientation: Angled LED indicators: Status and power Compliance: CE, cULus Listed Dimensions (HxWxD): Approx. 50 × 18 × 36 mm Part number: 1041436 Made in: Germany Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   2.00

Depth:   6.00

Length:   6.00

Width:   6.00

SKU:   275780 4.S3.0.3.3
