In stock 1 available
The Ametek Model 575 Series is a robust, intrinsically safe submersible level transmitter designed for continuous hydrostatic level measurement in water, wastewater, and industrial applications. It offers reliable 4–20 mA output and is easy to install by direct submergence into tanks, wells, or open bodies of water. Model: 575 Series Measurement Principle: Hydrostatic pressure via ion-implanted silicon sensor with Wheatstone bridge Output Signal: 4–20 mA, 2-wire loop-powered Power Supply: 12–28 VDC Pressure Ranges: 0–6 psi (13.8 ft H₂O) to 0–300 psi (690 ft H₂O) Accuracy: ±0.25% FS (BFSL) typical Diaphragm Material: 316L Stainless Steel (standard), Hastelloy C (optional for 575P) Housing Material: 316 Stainless Steel Fill Fluid: Silicone oil Cable Options: Polyurethane or Teflon jacket; lengths up to 2500 ft Sensing Port Options: Delrin snub nose, flush diaphragm, or protected flush cage Operating Temperature: -20°C to +60°C Approvals: CSA Intrinsically Safe (when used with approved safety barrier) Applications: Water/wastewater treatment, lift stations, reservoirs, wells, industrial tanks, sludge, and slurry measurement Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 6.00
Depth: 12.00
Length: 12.00
Width: 12.00
SKU: 275802 4.S2.16.3
