Tri-Mag PA6-10E EMI/RFI Filter, 6A 115/250VAC

Tri-Mag PA6-10E EMI/RFI Filter is a general-purpose single-phase power line filter designed to suppress electromagnetic and radio frequency interference in AC power systems. It is suitable for applications requiring up to 6 A current handling at voltages of 115/250 VAC. Technical Specifications: Model: PA6-10E Rated current: 6 A Rated voltage: 115/250 VAC Frequency range: 47–63 Hz Leakage current: 0.25 mA max at 115 VAC 0.50 mA max at 250 VAC Hipot rating: Line-to-ground: 2000 VAC Line-to-line: 1750 VDC Insertion loss (typical): Common mode (line-to-ground): up to 55 dB at 10 MHz Differential mode (line-to-line): up to 65 dB at 10 MHz Mounting type: Chassis mount Terminations: Quick connect terminals Dimensions: Length: 2.50 inches Width: 2.00 inches Height: 1.50 inches Mounting hole spacing: 2.94 inches Applications: Systems with switching power supplies, computers, process control equipment Manufacturer: Tri-Mag, LLC Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.50

Depth:   4.00

Length:   7.00

Width:   7.00

SKU:   3014 4.S8.15.3
