Contec DA12-2(98) Circuit Board

The Contec DA12-2(98) is a multifunction analog output board designed for use in industrial PC-based control systems. It provides multiple channels of analog voltage output with high resolution and is suitable for test, measurement, and automation tasks. Model: DA12-2(98) Board Type: Analog Output (D/A Conversion) Bus Interface: ISA Bus (16-bit) Number of Output Channels: 2 channels Resolution: 12-bit D/A conversion Output Voltage Range: ±10 V (bipolar output) Output Type: Voltage Output Settling Time: Approx. 10 µs (typical) Output Drive Capability: ±5 mA (typical) Connector Type: 37-pin D-sub Operating Temperature: 0 to 50°C Power Requirements: Supplied through ISA bus Applications: Data acquisition, process control, laboratory instrumentation, industrial automation systems Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.70

Depth:   6.00

Length:   10.00

Width:   9.00

SKU:   319 4.S8.7.3C
