Contec DA12-2(98) Circuit Board

The Contec DA12-2(98) is a multifunction analog output board designed for use in industrial PC-based control systems. It provides multiple channels of analog voltage output with high resolution and is suitable for test, measurement, and automation tasks.

Model: DA12-2(98)
Board Type: Analog Output (D/A Conversion)
Bus Interface: ISA Bus (16-bit)
Number of Output Channels: 2 channels
Resolution: 12-bit D/A conversion
Output Voltage Range: ±10 V (bipolar output)
Output Type: Voltage Output
Settling Time: Approx. 10 µs (typical)
Output Drive Capability: ±5 mA (typical)
Connector Type: 37-pin D-sub
Operating Temperature: 0 to 50°C
Power Requirements: Supplied through ISA bus
Applications: Data acquisition, process control, laboratory instrumentation, industrial automation systems Please review pictures carefully and let us know if you have any questions!
