Browning VF4S-110 Flange Mounted Bearing 5/8" RF-4501

The Browning VF4S-110 is a 4-bolt flange-mounted ball bearing unit designed for industrial applications requiring secure mounting and reliable shaft support. It features a 5/8-inch bore and is pre-lubricated for extended service life with minimal maintenance.

Model: VF4S-110
Part Reference: RF-4501
Bearing Type: Ball Bearing
Mounting Style: 4-Bolt Flange
Bore Size: 5/8 inch (0.625")
Housing Material: Cast Iron
Bearing Insert: Spherical OD, setscrew locking
Seal Type: Contact seal with anti-rotation device
Lubrication: Factory lubricated, re-lube capable (grease fitting)
Bolt Hole Center-to-Center: 3.250 inches (square pattern)
Overall Housing Width: 0.875 inches (nominal)
Temperature Range: -20°F to 200°F (typical)
Applications: Conveyors, agricultural equipment, machinery support shafts, light industrial systems Please review pictures carefully and let us know if you have any questions!
