Mitsubishi Electric NF-SF3100 3-Pole Circuit Breaker, 100A 480VAC

The Mitsubishi NF-SF3100 is a molded case circuit breaker (MCCB) designed for industrial power distribution and protection applications. It offers reliable overcurrent and short-circuit protection for 3-phase systems. Model: NF-SF3100 Type: Molded Case Circuit Breaker (MCCB) Poles: 3-Pole Rated Current: 100 A Rated Voltage: 480 VAC Interrupting Capacity: Typically 25 kA at 480 VAC (verify variant-specific rating) Frequency: 50/60 Hz Mounting: Panel mount Trip Mechanism: Thermal-magnetic (fixed or adjustable depending on model) Standards Compliance: IEC 60947-2, JIS, UL489 (for global variants) Application: Motor feeders, branch circuit protection, panelboards, and control panels Manufacturer: Mitsubishi Electric Country of Origin: Japan Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   4.00

Depth:   6.00

Length:   12.00

Width:   9.00

SKU:   3544 4.S7.21.3
