Fuji Electric SC-E03 SE12AA Starter/Contactor, 600VAC 20A 120VAC Coil

The Fuji Electric SC-E03 SE12AA is a compact magnetic contactor designed for motor control and general-purpose switching applications. Rated for AC and DC control, it is suitable for use in circuits up to 600 VAC and supports 20A continuous current. Technical Specifications: Model: SC-E03 Series: SE12AA Control Voltage: 100–120 VAC (coil) Rated Operational Voltage: 600 VAC max Rated Insulation Voltage: 690 V Continuous Current Rating: 20 A Utilization Category: AC-3 Motor Ratings (3-phase, 50/60 Hz): 240V – 3.7 kW, 440V – 5.5 kW, 550V – 5.5 kW Horsepower Rating (1PH): 1/2 HP at 120V, 2 HP at 240V Horsepower Rating (3PH): 3 HP at 200V, 7.5 HP at 460/575V Short Circuit Rating: 5kA, 600V (with fuse class RK5 30A or CB 15A) Main Contacts: 3 poles (L1, L2, L3 / T1, T2, T3) Mounting Type: DIN rail or screw mount Standards: UL Listed, CE, TÜV Rheinland Country of Manufacture: Japan Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.16

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   3742 4.S4.14.2
