Fuji Electric TK-5-1N TR20E Overload Relay, 0.95-1.45A 600VAC

The Fuji Electric TK-5-1N TR20E is a thermal overload relay designed for protection of motors and circuits against overload and phase failure. It features adjustable current settings and is suitable for systems operating up to 600 VAC. Technical Specifications: Model: TK-5-1N TR20E Type: Thermal Overload Relay Current Adjustment Range: 0.95–1.45 A Rated Operational Voltage: Up to 600 VAC Trip Class: 10 Poles: 3-pole protection Reset Method: Manual and automatic Auxiliary Contacts: 1 NO + 1 NC Mounting: Direct mount onto compatible Fuji SC series contactors Ambient Temperature Compensation: Yes Trip Indication: Mechanical flag Protection Functions: Overload and phase failure protection Certifications: UL, CSA, IEC compliant Application: Small motor and control circuit protection in industrial systems Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.50

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   3780 4.S10.1.3I
