Omron C200HW-NC413 NC Unit 24VDC

The Omron C200HW-NC413 is a high-performance 4-axis position control module for the Omron C200H series PLC system. It outputs pulse string signals and supports precise motion control applications for stepper or servo motor systems. Model: C200HW-NC413 Type: NC Unit (Position Control Unit) Control Axis: 4-axis independent control Output Type: Pulse string output Maximum Output Frequency: 500 kHz per axis Compatible Motors: Stepper or pulse-input servo motors Power Supply: 24 VDC Control Method: Open-loop or closed-loop (with external feedback) I/O Interface: 40-pin dual-row header connector Mounting: PLC rack mount (C200H series backplane) Certifications: UL, CE, CSA compliant Applications: Multi-axis positioning systems, CNC tables, pick-and-place automation, robotics, and advanced motion tasks in industrial PLC environments Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   1.50

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   388 4.S8.12.1
