Technical Specifications
| Attribute | Details |
|---|---|
| Series | LFR‑M1 (mini) |
| Pneumatic Connection | G1/4″ (filter/regulator) |
| Pressure Gauge Port | G1/4″ |
| Regulation Range | 0.5 … 10 bar (7 … 145 psi) |
| Operating Pressure | max. 10 bar |
| Flow Rate | Typically 1,150–3,400 L/min (varies by configuration) :contentReference[oaicite:1]{index=1} |
| Filtration Grade | 5 µm (C = clean) :contentReference[oaicite:2]{index=2} |
| Ambient Temperature | –20 °C … +60 °C (–4 °F … +140 °F) :contentReference[oaicite:3]{index=3} |
| Media Temperature | Same as ambient |
| Material | Metal body, POM knob, NBR seals, PC bowl |
| Condensate Drain | Manual rotary |
| Lockable Pressure Setting | Rotary knob with detent :contentReference[oaicite:4]{index=4} |
| Construction | Mini compact design |
| Standards | ISO 8573-1 for compressed air quality, CRC‑3 corrosion resistance :contentReference[oaicite:5]{index=5} |
