Analog Devices 3B41-02 Isolated Wideband V Input Module

The Analog Devices 3B41-02 is a wideband signal conditioning module designed for voltage input applications. It provides precise voltage-to-voltage or voltage-to-current conversion with full three-way isolation, making it suitable for use in industrial data acquisition and control systems.

Model: 3B41-02
Type: Isolated Wideband Voltage Input Module
Input Range: ±10 V
Voltage Output (V OUT): ±10 V
Current Output (I OUT): 4–20 mA (optional or configured)
Bandwidth: Wideband (100 kHz typical)
Isolation: Input-to-output-to-power supply galvanic isolation
Mounting: DIN rail or panel-mount on backplane
Connector: Edge card style with gold fingers
Accuracy: High linearity, low drift
Manufacturer: Analog Devices
Country of Origin: Made in U.S.A.
Applications: Industrial signal monitoring, high-speed data acquisition, analog I/O interface in PLC and DCS systems, isolation of noisy analog sources Please review pictures carefully and let us know if you have any questions!
