Analog Devices 3B47-T-07 Isolated Linearized TC Input Module

The Analog Devices 3B47-T-07 is a precision signal conditioning module designed to interface directly with thermocouple sensors. It provides cold junction compensation, linearization, and galvanic isolation, ideal for accurate temperature monitoring in industrial environments.

Model: 3B47-T-07
Type: Isolated Linearized Thermocouple (TC) Input
Thermocouple Type: J (Iron-Constantan)
Input Range: 0°C to +500°C
Voltage Output (V OUT): 0 to +10 V DC
Current Output (I OUT): Not available on this variant (voltage output only)
Cold Junction Compensation: Integrated, automatic
Linearity: Factory-calibrated linearized output
Isolation: 1500 V RMS galvanic isolation (input/output/power)
Mounting: 3B series backplane or DIN carrier
Connector: Edge card connector (standard 10-pin format)
Manufacturer: Analog Devices
Made in: U.S.A.
Applications: Industrial temperature monitoring, thermal process control, data logging systems, HVAC equipment, and automated manufacturing environments Please review pictures carefully and let us know if you have any questions!
