Allen-Bradley 1756-SYNCH SER.A ControlLogix Synchlink Communications Module

Allen-Bradley 1756-SYNCH SER.A is a ControlLogix SynchLink communication module designed for high-speed, deterministic data transfer between multiple chassis in a ControlLogix system using fiber-optic SynchLink networks. Module Type: SynchLink Communication Module Catalog Number: 1756-SYNCH Series: A Compatibility: ControlLogix system Communication Method: SynchLink fiber-optic network Max Number of Nodes: Up to 32 modules per SynchLink network Data Transfer Rate: 655 Mbps (maximum effective data throughput) Connector Type: Duplex fiber optic ST connectors Distance Supported: Up to 2000 meters (6562 feet) multimode fiber Power Requirements: 450 mA @ 5.1V DC, 3 mA @ 24V DC Slot Requirement: 1 slot in ControlLogix chassis Backplane Communication: Compatible with Logix controller via backplane Operating Temperature: 0°C to 60°C (32°F to 140°F) Storage Temperature: -40°C to 85°C (-40°F to 185°F) Relative Humidity: 5% to 95% non-condensing Certifications: UL, CE, CSA, C-Tick

Condition: Used

Weight:   5.00

Depth:   5.00

Length:   12.00

Width:   9.00

SKU:   43513 4.S2.12.2B
